Features & specs
| General | ||
|---|---|---|
| Speaker Size | 6 1/2 | |
| Design | 3-way | |
| Tweeter Design | 29mm Dome | |
| Impedance (Ohms) | 4 | |
| Tweeter Composition | Tetolon | |
| Woofer Composition | Pressed Pulp/Cotton Fiber | |
| Woofer Surround | Rubber | |
| Parts Warranty | 2 Years | |
| Labor Warranty | 2 Years | |
| Specifications | ||
| Sensitivity (1W at 1 meter) | 92 | |
| Sensitivity at 2.83 volts | N/A | |
| Frequency Response | 40 - 22.5k Hz | |
| Minimum RMS Wattage | --- | |
| Maximum RMS Wattage | 150 | |
| Peak Power Handling (Watts) | 300 | |
| Top-mount Depth (Inches) | 2 1/2 | |
| Bottom-mount Depth (Inches) | 2 11/16 | |
| Cutout Diameter or Length (inches) | 5 1/2 | |
| Mounting Height (Inches) | 0.42 | |
| Frame Width | 6.502 | |
| Frame Length | 6.502 | |
Product Research
Features
Size Classification Note: Some manufacturers, including Hertz, call this size woofer a 6-1/2". Because it requires a larger cutout than a standard 6-1/2" speaker, Crutchfield has traditionally referred to this size as a 6-3/4". Please enter you vehicle information to confirm fit in your vehicle.
Boundary Free Surround: This technology provides more woofer cone surface area than other speakers of the same size, enabling it to move more air. The surrounds are made of rubber, ensuring thermal and mechanical linearity.
Klippel Verified: The Klippel distortion analyzer, a device that uses a laser and computer software to do large-scale analysis of drivers in motion, helps Hertz optimize the speaker's motor structure, voice coil alignment, and suspension to yield the best possible performance.
Grilles: The three piece woofer and midrange grilles can be used several different ways. All three pieces (black plastic frame, gray plastic inner grill, and black steel mesh) can be mounted together. The frame and mesh can be mounted without the inner grille, the frame and inner grille can be mounted without the mesh, and the inner grille can be mounted alone.
Tweeter Mounting: Brackets are included for flush mounting, angled surface mounting (60° or 30°), and mounting behind the factory grille.
Tweeter Mounting Dimensions:
| Flush Mount | 60° Angled Surface Mount | 30° Angled Surface Mount | Top Mount (behind factory grille) | Bottom Mount (behind factory grille) | |
|---|---|---|---|---|---|
| Mounting Height | 0.437" | 1.577" | 1.885" | 0.965" | 0.357" |
| Depth | 0.628" | N/A | N/A | 0.1" | 0.708" |
| Frame Diameter | 2.217" | N/A | N/A | 1.971" | 1.971" |
| Cutout Diameter | 1.605" | N/A | N/A | 1.306" (minimum) | 1.798" (minimum) |
| Frame Width | N/A | 1.787" | 1.787" | N/A | N/A |
| Frame Depth | N/A | 1.883" | 1.562" | N/A | N/A |
Crossovers: Each crossover has midrange and tweeter output level switches; independently choose between flat and +2dB for each. The low pass crossover point is 450 Hz with a 6 dB/octave slope. The band pass output is 450 Hz to 5.5 kHz with a 6 dB/octave slope at both ends. The high pass crossover point is 5.5 kHz with a 12 dB/octave slope. They have screw terminal inputs and outputs that will accept bare wire or spade connectors up to 0.315" wide.
Crossover Dimensions:
- Width: 5-3/4"
- Height: 1-5/8"
- Depth: 4-1/2"
