Features & specs
General | ||
---|---|---|
Speaker Size | 6 1/2 | |
Design | 2-way | |
Tweeter Design | 0.9" Dome | |
Impedance (Ohms) | 4 | |
Tweeter Composition | Tetolon | |
Woofer Composition | Pressed Paper | |
Woofer Surround | Butyl Rubber | |
Parts Warranty | 2 Years | |
Labor Warranty | 2 Years | |
Specifications | ||
Sensitivity (1W at 1 meter) | 92 | |
Sensitivity at 2.83 volts | N/A | |
Frequency Response | 45 - 22k Hz | |
Minimum RMS Wattage | --- | |
Maximum RMS Wattage | 95 | |
Peak Power Handling (Watts) | 285 | |
Top-mount Depth (Inches) | 2 5/8 | |
Bottom-mount Depth (Inches) | 2 13/16 | |
Cutout Diameter or Length (inches) | 5 9/16 | |
Mounting Height (Inches) | 0.704 | |
Frame Width | 6.505 | |
Frame Length | 6.505 |
Product Research
Features
Size Classification Note: Some manufacturers, including Hertz, call this size speaker a 6-1/2". Because it requires a larger cutout than a standard 6-1/2" speaker, Crutchfield has traditionally referred to this size speaker as a 6-3/4". Please enter your vehicle information to confirm fit.
Klippel Verified: The Klippel distortion analyzer, a device that uses a laser and computer software to do large-scale analysis of drivers in motion, helps Hertz optimize the speaker's motor structure, voice coil alignment, and suspension to yield the best possible performance.
